Products > OTR > Large Bore Components

Large Bore Components

To View Dill’s Large Bore Catalog, Click Here
211 Large Bore Component product image
211
301A Large Bore Component product image
301A
302A Large Bore Component product image
302A
6489 Large Bore Component product image
6489
6489A Large Bore Component product image
6489A
70-HT Large Bore Component product image
70-HT
8771 Large Bore Component product image
8771
8807 Large Bore Component product image
8807
9061 Large Bore Component product image
9061
HN-80 Super Large Bore product image
HN-80
J-670-3-USA Large Bore Component product image
J-670-3-USA
J-670-USA Large Bore Component product image
J-670-USA
J/670/SCR Large Bore Component product image
J/670/SCR
447 Large Bore Component product image
447
454 Large Bore Component product image
454
8771A Large Bore Component product image
8771A
CH-16 Super Large Bore product image
CH-16
CH-3D Large Bore Component product image
CH-3D
CH-8 Large Bore Component product image
CH-8
CH3-F Large Bore Component product image
CH3-F
VS-902-WZP-10 Large Bore Component product image
VS-902-WZP-10
VS-902-WZPL Large Bore Component product image
VS-902-WZPL
VS-977 Large Bore Component product image
VS-977
VS-977P Large Bore Component product image
VS-977P

Product Inquiry

  • This field is for validation purposes and should be left unchanged.

Location

Dill Air Controls Products
1500 Williamsboro St.
PO Box 159
Oxford, NC 27565

Get Directions

View Map & Directions

DILL P/N TR P/N MADE IN USA HEIGHT BEND ANGLE EFFECTIVE LENGTH VALVE HOLE DESCRIPTION PART INFORMATION A B C D Y Z TORQUE (HEX NUT) TORQUE (CORE HOUSING)
211 HN-1
Hex Nut Fits 0.486-26 thread on Large Bore; Brass - 5/8" hex 45-75 in. lbs. 3 in. lbs.
301A -
Extension 90° bend, 3.66" effective length; for tube valve applications
302A -
Extension 80° bend, 1.78" effective length; for tube valve applications
6489 CH1
Core Housing Fits old style TR 218 & TR 220 valves
6489A CH3
Core Housing Standard bore with octagon grip; O-ring seal
70-HT
Valve Core Max working pressure: 450psig -65°F to 250°F ; 0.13" pin travel Viton cup seal material Standard: TR C2,A-A-52611; Opening Pressure: 35 psi; Temperature Range (°F): -65 to 250; Cup Seal Material: Silicone; 0.13" pin travel
8771 LN-10
Lock Nut For TR 218A/220A; Brass
8807 AD1
Adapter Reduces large bore to standard bore; fits inside 0.305.32 valve core threads
9061 AD1
Adapter Reduces large bore to standard bore; fits over 0.485-26 valve cap threads
HN-80 HN-80
Hex Nut Fits 0.687-24 thread; Brass - 15/16" hex
J-670-3-USA J670-03
1.42" - -
J-670-USA J670-02
Core Housing Fits TR SP1000 spud; includes hex valve cap
J/670/SCR J670-02
Core Housing Fits TR SP1000 spud; includes screwdriver valve cap
447 RG-7 EPDM Grommet Fits TR 618A-623A air/liquid valves 45-75 in. lbs. 3 in. lbs.
454 RG-22 EPDM Grommet Fits TR SP2 spud 45-75 in. lbs. 3 in. lbs.
8771A LN-10 Lock Nut For TR 218A/220A; Nylon
CH-16 CH16 Core Housing Air/liquid core housing for TR SP8 or TR SP9 spuds 0.62" 3.31" - - - 18°
CH-3D CH3 Core Housing Standard bore with knurled grip; O-ring seal 1.25" 4.69" 2.31" 0.56" 18° 28°
CH-8 CH8 Core Housing Used with large and super large bore spuds; utilizes an O-ring seal
CH3-F CH3 Core Housing Standard bore with ribbed grip; O-ring seal 0.88" 5.00" 1.69" 0.81" 45° 45°
VS-902-WZP-10 - Valve hole plug Plug seal for 0.625" valve hole; 0.70" effective length
VS-902-WZPL - 1.15" 0.625" Long valve hole plug Longer version of VS-902-WZP-10
VS-977 SP2 Valve Spud Tubeless spud for large bore swivel valves; fits 0.812" valve hole
VS-977P SP2 Valve Hole Plug Plug seal for 0.812" valve hole
